Frey Battery (North America)
FGB-Series
| General Technical Specification | |
|---|---|
| Application : | Golf Carts, Utility Vehicles, Mobility Scooters, Aerial Platform Lifts |
| Nominal Voltage : | 24V(25.6V), 36V(38.4V), 48V(51.2), 72V(73.6V) |
| Available Capacity : | 105Ah, 160Ah |
| Battery Dimension & Weight : | Customizable solution to meet specific power needs |
- Patented Nano LiFePO4 cathode℗ technology
- Maximum 0.5C fast charging current
- Integrated battery management system (BMS)
- Built-in SoC meter displays real-time battery capacity
- Wide operating temperature range
- Battery heating mechanism under extreme cold conditions
- Bluetooth app provides real-time data on battery status, voltage, current, and more
- Long cycle life > 3000 cycles (80% DOD)
Safety
Outstanding results from comprehensive and destructive testing on both cell and module levels. These tests include nail puncture, short circuit, extreme high temperature, extrusion, drop test, fire, and explosion performance.
Reliability
The design lifespan of the product is 20,000 hours on an 8-hour shift operation with remaining capacity 80% at the end of the design life.
Quality Assurance
ISO 9001, CE, UN38.3, RoHs, MSDS
Long Life
Battery life is extended by approximately 20% when the depth of discharge remains below 80% and the battery receives a full charge once a week.
